Interstate 19X LE Outland Edition
Specs & Features
Everything you need to know—from dimensions to features.
Size & Towing
- Exterior Length
- 20 ft 1 in
- Exterior Width
- 7 ft 8.5 in (with Mirrors)
- Exterior Height
- 9 ft 10 in (with A/C)
- Interior Width
- 5 ft 10 in
- Interior Height
- 6 ft 2.5 in
- Unit Base Weight
- 7,350 lbs
- Gross Vehicle Weight Rating (GVWR)
- 9,050 lbs
- Gross Combined Weight Rating (GCWR)
- 13,930 lbs
- Net Carrying Capacity (NCC)
- 1,923 lbs
- Hitch Weight
- 500 lbs
- Tow Capacity
- Up to 5,000 lbs
- Features
- Mercedes-Benz® Hitch with 7 Pin Trailer Plug and Brake Control Pre-wired
Chassis & Powertrain
- Chassis
- Mercedes-Benz® Sprinter 2500
- Drivetrain
- AWD
- Engine
- Mercedes-Benz® 2.0L Turbo Charged 4-Cylinder High Output Diesel
- Transmission
- 9G-TRONIC Plus Automatic
- Wheelbase
- 144 in
- Horsepower / Torque
- 208 HP / 332 lb Torque
- MPG
- 16-18+ Estimated Highway
- Emissions
- BlueTEC SCR Technology | 50 State – EPA/CARB Standards
- Fuel Type
- Diesel
- Fuel Tank
- 24.5 gal
- Suspension
- Van Compass Stage 6.3
- Cab and Convenience Features
- 10.25 in MBUX Infotainment System (Mercedes-Benz User Experience)
- Advanced Multifunctional Steering Wheel with Capacitive Touch Controls
- Advanced Navigation
- Electrically Heated Windshield
- Google Android Auto/ Apple Carplay
- Heated Steering Wheel
- In-Dash Maintenance Monitoring System
- In-Dash Wireless Cell Phone Charging
- Overhead Cab Shelf
- Overhead Map Lights
- Power Adjustable | Heated and Swivel Driver/Passenger Seats
- Power Folding And Heated Mirrors
- Push Button Keyless Start
- Steering Wheel Paddle Shifters
- THERMOTRONIC Automatic Climate Control
- Tilt and Telescopic Leather Steering Wheel
Energy & Power
- Battery Capacity
- 2.5 kWh Heated Lithium Batteries with Remote Monitoring (Only Available with Solar Options)
- Optional Battery Upgrade
- E1 Package (Optional)
- Solar Charging System
- 250 W Solar System
- Supplemental Solar Pre-Wire Port
- Curb and Street Side Exterior Ports for Additional Solar Panels
- Converter
- 80 A (Multi-Stage Charger)
- Inverter
- 2000 W (Pure Sine Xantrex Inverter)
- Generator/Alternator
- 2.5 kW (LPG) Ultra Quiet Generator with Remote Start
- Shore Power
- 30 A Service with Smart Plug
- Multiplex System Display
- Multiplex Bluetooth App Control System with Touch Screen for Energy Management System
- USB Ports
- USB Charging Ports
Tank Capacities & Utility
- Fresh Water Tank
- 20 gal
- Gray Water Tank
- 16 gal
- Waste Tank
- 9 gal
- Holding Tank Disposal
- Macerator Pump System with Electric Retract
- Heated Tanks
- Heated Fresh and Gray Tanks (12 V)
Sleeping & Seating
- Sleeping Capacity
- Up to 2
- Convertible Sleeping Space
- 54 in x 75 in bed that includes Sleep Under Stars option. Sleeps partially outside under the awning or inside
- Seating Capacity - Belted Positions
- Up to 2
Climate & Comfort
- Air Conditioner - Primary
- 13,500 BTU with Soft Start
- Heating Source
- 14,300 BTU Truma Combi Eco Plus Furnace
- Water Heating Source
- 14,300 BTU Truma Combi Eco Plus Furnace
Galley
- Cooktop
- 1,000 W Single Burner Induction with Custom Cutting Board
- Microwave
- 0.7 cu ft Locker Microwave
- Refrigerator with Freezer
- Dometic CFX3 powered portable refrigerator with articulating mount for exterior use
- Galley Surface
- Solid Surface Countertop with Aluminum Backsplash
- Sink & Faucet
- High Quality Faucet
- Stainless Steel Sink with Cover
- Features
- Aluminum Refrigerator Fascia
- Under Counter Lighting
Dinette & Lounge
- Dinette
- Colorado Black Ultraleather with Mountain Peak Insets (front seats)
- Simtex Marine-Grade Carbon Gray (rear seating/sleeping)
- Ultraleather® Seating
- Features
- Interior table mounts and an additional exterior mount on rear door hinger for outdoor workspace.
Bathroom
- Configuration
- Space-Saving Wet Bath
- Toilet
- Plastic Toilet with Foot Flush
- Shower
- Removable Hand Held Shower Head
- Sink & Faucet
- Sink with Articulated Mirror
- Vent/Exhaust Fan
- Exhaust Fan
- Retractable Clothes Line
- Standard
- Features
- Integrated LED Shower Lighting
- Riveted Aluminum Porthole Door
- Towel Rack
Entertainment & Connectivity
- Living Area | Front TV
- Prewired for TV
- Audio
- 1200W Sony DSX-GS80 Digital Media Receiver with 4 8 in 200 W REV* Black V2 speakers and a ZERO Series 400 W 12 in Subwoofer
- Bring Your Own Device Connection
- HDMI Pre-Wire
- Installed Antenna
- Omni-Directional Antenna
- Antenna Pre-Wiring
- Pre-wired for Connected Service
- Exterior Media Connection
- Exterior TV and Internet Inlets (Coax and Ethernet Cat6)
Interior Features
- Window Shades & Screens
- Front Cabin Window Covers
- Snap-on Night Shades
- Vented Cockpit Windows
- Lighting
- COB Series dimmable LED strip lights and cabinet accent lights
- Entry Door Lighting
- Storage
- Aluminum Aircraft L-Track Storage System
- Flex Storage Solutions
- Overhead Storage Compartments/Solutions
- Underbed Interior Storage
- Safety
- Smoke and CO2 Alarm | Fire Extinguisher | First Aid Kit
- Flooring
- Rugged Grey Flooring (waterproof | stain and scratch Resistant)
- Exhaust Fan
- Exhaust Fan with Rain Sensor
- Cabinetry
- Flush-Mount Cabinet Hardware and Soft Close Doors
- Matte Laminate Cabinetry
- Features
- 12 V Water Pump with Controller
- Signature Aluminum Ceiling and Trim
Exterior Features
- Style Elements
- Chrome Grille
- Durable Black Protective Coating (Front Hood | Bumpers | Lower Side Moldings)
- Tenzing Front Brush Guard with HD LED Lights
- Awning
- Overland Vehicle Systems 270-degree awning system with LED lighting
- Lighting
- LED Patio and Awning Lighting
- LED Undercarriage Lights
- Rough Country 6 in Cree LED light bars - 3 | Hood Vent 6 in | Cree LED lights - 2
- Exterior Outlets
- 110 V Outlet
- Safety
- Locking Service Boxes
- Exterior Shower
- Exterior Shower with Hot and Cold Water
- Tires
- Black Aluminum Wheels
- Storyteller 18 in Wheels and BF Goodrich 275/65/R18 T/A KO2 Tires
- Windows & Entry
- Black Running Boards (Driver/Passenger side)
- Zippered Screen Door System (rear)
- Features
- Winterization Valve
Membership & Warranty
- Airstream Warranty
- 2 Year Airstream Limited Warranty (Transferable)
- Chassis Warranty
- 5 Years/100,000 Miles Mercedes-Benz® Engine and Drive Train
- 5 Years/75,000 Miles Mercedes-Benz® Chassis
- Airstream Club Membership
- 1 Year Airstream Club Explorer Membership
- Additional Benefits
- 3 Year 24/7 Coach-Net® Roadside Assistance
Additional
- Certification
- TRA Certification™ Green: Emerald Status (Highest Rating)
